Elecbee P32 10 Pin Female Plug Straight Soldered P32K11S Aviation Connector

SKU: EB-401-4056-L
お気に入り
主要特徴

Features:

  • With anti-missing design
  • Good insulation performance
  • Stable work performance
  • Simple structure, convenient user wiring
  • Easy installation
  • Cost-effective
もっと見る
属性
Connector Type
Plug
Mounting Type
Cable Type
Termination
Solder
Contact Type
Female Pin
Shell Finish
Chrome Plated
Number of Positions
10 Pin
Operating Temperature
-20℃~+85℃
Rated Current
10A, 25A
Rated Voltage
250VAC, 380VAC
Connector Series
P32
Color
Taupe
Fastening Type
Threaded
Orientation
Right Angled
Shell Material
Zinc Alloy
Contact Material
Copper Alloy
Contact Finish
Gold Plated, Silver Plated
Insulating Materials
PA66, GF20
Cable Diameter
18mm~20mm
Shell Size
32
Insulation Color
Black
