Elecbee 3G 4G LTE Low Profile Outside Vehicle Donor Antenna for Car, Truck, RV w/SMA Connector

SKU: EB-201-2389

お気に入り

主要特徴

説明

Product Description

Car Roof Antenna with SMA Connector | weBoost 301126 by Wilson Electronics.

Magnet base 3G 4G LTE low profile outside vehicle donor antenna for auto, car, pickup truck, RV, SUV is a 50 ohm antenna for catching wireless signals from nearest cell towers. It has SMA-Male connector, which is the screw-on type.

Installation is simple: Place this mag. mount antenna on roof of vehicle where it will stick magnetically. This antenna will work with any multi-user vehicle cell phone boosters, including the SureCall Fusion2Go series and weBoost Drive series kits.

This omni-directional magnet mount antenna's height is 4.18 inches. It has 10 feet LMR-100 cable attached to it with SMA Male connector at its end. It is the standard antenna included in weBoost Drive 4G-X and 4G-M kits.

Installation:

Identify a location on the top of your vehicle that is near the center of the roof. Place atleast 12 inches away from any other antennas and from any windows (including sunroofs). Clean the surface where you will place the outside antenna. Mount the outside antenna by placing on top of vehicle. NOTE: For aluminum roofs, use the included adhesive disk to secure outside antenna in place.

How can the cable can be routed with different vehicles?

The cable is strong enough that it may be shut in most vehicle doors without damaging the cable.

Car/ Sedan: Cable routed into rear side door.
SUV/ Van/ Hatchback: Cable routed into top of hatchback door.
Truck: Cable routed into side door.

NOTE: When going through car wash, remember to remove your antenna.

Features:

Works on all worldwide cellular bands for voice and 4G data: LTE/ CDMA/ GSM/ UMTS/ AWS.
High performance for all cellular repeaters and boosters.
Supports 4G LTE, 3G & 2G.
Designed for exterior vehicle installation.
High efficiency & compact low profile design that blends into any vehicle type.
Rugged & waterproof for all weather operation.
Simple install.
Ground plane independent.
2-year warranty.

Highlights:

Covers all 4G 700 - 2300MHz cellular frequencies All modes, voice and data.
All M2M applications.
High gain signal output surpasses others this size.
Install instantly on any steel surface (required).
Portable and easy to store.
Outdoor rated waterproof.
Great for cars and trucks.
Connects to cellular boosters and modems.
Assembled in USA.

Specifications:

Frequency Band (MHz)	700-800 \| 824-894 \| 1710-1880 \| 1850-1990 \| 2110-2170
Mount Type	Rare Earth Magnet
Peak Gain (dBi)	~1.7 \| ~2.1 \| ~2.2 \| 3.1 \| 1.4
Impedance (Ohm)	50
Polarization	Vertical
Radiation Pattern	Omni-Directional
Max Input Power	50W
Cable Type (ft.)	LMR-100 / RG-174
Cable Length (Feet)	10 / 12.5
Connector	SMA-Male
Water Resistance	IPX Weather Rated
Substance Compliance	RoHS
