What is an RJ45 Connector?

29/10/2022 Leon


As mentioned earlier, RJ45 is a highly modular 8P8C connector as it supports different wiring configurations. While you can make every possible combination, two very popular combinations include CAT5 and CAT6 cables. These are also known as T-568A and T-568B standards and they use the same connectors but have different wiring as shown:

If you're new to wired networks, maybe you're not familiar with the different devices and connectors used in them. This also includes the RJ45 connector, which is primarily used for Ethernet connections between various devices in any given wired network. The RJ45 connector is a very popular physical connector used in networking applications primarily for telephony.



The full name of the RJ45 connector happens to be the RJ45 8P8C plug. That just means it has eight positions and eight conductors in total. It is a modular connector for telecommunications and networking that can be adapted to your needs. As for its modern applications, it is mainly used to connect computers to LAN networks. You can learn more about RJ45 connectors by following factors one by one:



RJ stands for registered jack

While we've illustrated and explained some of the main importance of the RJ45 connector, some of you may also be interested in learning more about its name. RJ45 stands for Registered Jack 45, where the number 45 refers only to the standard shape of this connector.



As for the registered jack part, it just means that RJ45 is the physical standard used for network interfaces in various applications. As a physical standard, it sets the standard for wiring patterns used for RJ45 connectors. You can also find other RJ standard types of connectors such as RJ11, RJ14, RJ25, etc., which all have different sizes and functions.





RJ45 parts

Although RJ45 is used for various purposes, its construction is very simple because of its limited number of parts. In any given Rj45 connector you will find the following parts:



Copper pins for connecting copper wires

Clip for connecting and releasing RJ45 connector to RJ45 port

Crimp is used to secure the cable inside the RJ45 connector

All of these parts are present on both sides of an Ethernet cable with two RJ45 connectors.





RJ45 wiring

As mentioned earlier, RJ45 is a highly modular 8P8C connector as it supports different wiring configurations. While you can make every possible combination, two very popular combinations include CAT5 and CAT6 cables. These are also known as T-568A and T-568B standards and they use the same connectors but have different wiring as shown:



RJ45 connector used for

Now that you know more about the RJ45 connector and its physical structure, you may be interested in learning more about its applications and what RJ45 connectors are used for. The main application of RJ45 connectors is Ethernet cables, which are used to form networks.



Whether you're connecting computers to each other to form a local area network, or you want your system to be connected to the Internet, RJ45 allows you to do both. As for its original application and design reasons, RJ45 is mainly used in telecom and telephony applications to connect devices over long distances for communication.



In conclusion

After looking at all these details about the RJ45 connector, you must have a good understanding of its functions and features. In addition to the basics of the RJ45 connector, we also explain its components and wiring in detail. But most importantly, you can find some of the most common applications using RJ45 connectors. If you already know all the various details about the RJ45 connectors above, be sure to share your thoughts in the comments section.
