Micro USB Female Socket Type A DIP Straight Through Hole
- Specification
-
Product Attribute
Attribute Value
Search
-
Installation method
PCB Mount
-
Terminal type
Solder Type
-
Gender
Female
-
direction
Straight
-
Installation characteristics
Through Hole / Surface Mount
-
Number of Positions
5 pin
-
Port number
Single
-
waterproof level
Not Waterproof
-
Standard
USB 2.0
-
Connector Type
Micro A
- Description
Electrical Characteristics
- voltage Rating: 100V AC (rms)
- Current Rating: 1.0A MAX
- Contact Resistange: 10 milliohms max
- Insulation Resistange: 1000M ΩMin
- Dielectric Withstanding Voltage: 500 V DC/1min
Mechanical Characteristics
- Durability : 10,000 cycles
- Mating force: 35N max
- UNmating force: 10N
Environmental Characteristics
- Operating Temperature: -55°C to +85°C
Material:
| Part | Material | Finish |
| Housing | High temperature thermoplastic resin | UL94V-0 |
| Shield | Stainless Steel | Nickel Plating |
| Contact | Copper Alloy | Au over nickel |
