HK 18 Pin Female Insert Axial Screw Terminal
- HK,18,Female Contacts,母插体,PC,轴向压接,Axial Screw Terminal,母针,Copper Alloy,Silver
- Always the right plug-in connection for your requirements with three different series types
- Compatible connection: Housings are mounting and plug-in compatible with aluminum housings from well-known manufacturers
- Flexible combination: Variable connection technologies for contact inserts and terminal adapters
- Everything in one housing: Simply snap modular contact inserts for signals, data, power, and pneumatics onto the snap-in frame and mount them in the housing
- Reliable interfaces: All metal housings are EMC-ready with conductive surfaces and seals
- Specification
-
Product Attribute
Attribute Value
Search
-
plug-in syndrome
HK
-
Number of Positions
18 pin
-
Insert Type
Female Contacts
-
Insert Material
PC
-
Contact Termination
Axial Screw Terminal
-
Contact Type
Female Pin
-
Contact Material
Copper Alloy
-
Contact Plating
Silver
- Description
Applications Heavy-duty power inserts and modules can be used in a wide range of high and low voltage applications in a variety of industrial applications. Due to the nature of the environment connectors often require environmental protection ratings including IP68 and IP69K. Some of the most common are:
- Automation and control
- Robotics
- Industrial cable interfaces
- Signal, power and pneumatics interfaces
- Transportation and vehicles
- Manufacturing and production
Electrical properties
| Material | Polycarbonate |
| Pollution level | 3 |
| According to UL/CSA rated voltage | 600V |
| Insulation resistance | ≥1010Ω |
| Working temperature range | -40℃-+125℃ |
| Flame retardant grade | V0 |
| PIN | |
| Material | Copper alloy |
| Surface treatment | Silver plating |
| Contact resistance | ≤1mΩ |
| Wiring method | Screw crimping |
| Connect-disconnect life | ≥500 |
