2.92mm Male Solder Type Connector Straight for Semi-rigid Cable
- Specification
-
Product Attribute
Attribute Value
Search
-
Body Material
Steel
-
Installation method
Cable
-
Terminal type
Solder Type
-
Gender
Male
-
direction
Straight
-
Polarity
Standard
-
Function
Other
-
Installation characteristics
None
-
Impedance
50 Ω
-
Outer conductor connection
Solder
- Description
Electrical Characteristics
- Impedance: 50 Ohm
- Frequency range: DC~40GHz
- Voltage rating: 250 V(rms)
- Center contact resistance: <3.0mΩ
- Outer contact resistance: <2.0mΩ
- Insertion loss: <.05 sqrt(f(GHz)) dB
- VSWR: <1.30
Mechanical Characteristics
- Center contact retention force: >20 N
- Coupling test torque: 1.70 Nm
- Recommended torque: 0.8 Nm to 1.10 Nm
- Durability: >500 cycles
Environmental Characteristics
- Temperature Range：-65 ℃~+165 ℃
