Elecbee 6G Digital Programmable Attenuator 30DB Step 0.25DB OLED Display CNC Shell RF Module
SKU: EB0051117
Favorites
Key Features
Product Features:
The digital attenuator can adjust the signal level of the circuit in 0.25dB steps without interrupting the circuit. It can also be used as an in-machine attenuator for adjusting the power level in the test system. , High accuracy, stability and reliability, the use of OLED display attenuation, the attenuation can be controlled by the host computer.
Technical indicators:
1. Working frequency: LF-6GHz
2. Attenuation adjustment range: 0-31.75dB
3. Attenuation step: 0.25 (dB)
4. Insertion loss: ≤1.5dB (the insertion loss at the high frequency end will be a little larger)
5. Standing wave ratio: ≤1.4
6. Attenuation accuracy: ± 0.25dB Max
7. Rated power: ≤1W
8. Connector form: SMA (female, outer screw inner hole)
9. Temperature range: -10 ℃ ~ + 50 ℃ (operation), -40 ℃ ~ + 70 ℃ (not operation)
10. Dimensions: 55X40X16.5mm (excluding SMA interface protruding part, SMA protruding part 9mm)
11. Weight: 57g
12. Input and output impedance: 50 ohms
Show More
