Elecbee SHV Male Straight Back Mount Soldering Connector

SKU: EB-709-0004
Favorites
Key Features

Features:

  • SHV,Male,Straight,Back Mount,Soldering,Connector
  • Can be Customized for unique material or performance requirement;
  • Heat resistant insulators
  • Quick connect/disconnect bayonet coupling
  • Positive insulation grip

Applications:

  • nuclear instrumentation
  • Geiger counters
  • X-Ray
  • electrical transmission equipment.
Show More
Attribute
Value
Connector Type
Male
Number of Ports
1
Mounting Type
Panel Mount
Mounting Feature
Bulkhead - Rear Side Nut
Termination
Solder
Contact Type
Male Pin
Shell Finish
Silver Plated
Impendance
50 Ohms
Frequency Max
500 MHz
Connector Series
SHV
Color
Silver
Fastening Type
Threaded
Orientation
Straight
Shell Material
Copper Alloy
Shield Termination
Solder
