商品图

Elecbee SMA Male To SMA Male 0-18Ghz High Frequency Stainless Steel Rf Coax Connector

SKU: EB-DRF-0172
Favorites
Key Features

Features:

  • SMA Connector, SMA  male to SMA  male, Straight,  Stainless Steel,High frequency RF coax connector;
  •  Operation from DC to 26.5 GHz
  • Impedance: 50 Ω
  • Dielectric: Air
  • Ideal PCB connector solution for high-frequency applications
  • Optimized end launch design with through-hole legs or traditional slide-on mounting legs
  • Available for multiple different PCB thicknesses
  • Interface Standards: IEEE 287-2007

Appliance:

  • Cellular/Broadband amplifiers
  • Radar systems
  • High-speed routers and switches
  • Microwave filters
  • Wireless infrastructures
  • Remote sensing and metering
  • RFID
  • GPS antennas
Show More
Attribute
Value
Mounting Type
Cable Type
Shell Finish
Nickel Plated
1st Contact Type
Male Pin
2nd Contact Type
Male Pin
Frequency Max
18 GHz
Shell Material
Stainless steel
Conversion Series
Same Series
Convert From(Adapter 1)
SMA
1st Connector Fastening Type
Threaded
Convert To(Adapter 2)
SMA
2st Connector Fastening Type
Threaded
Adapter Style
Straight
