Elecbee 2.92MM Male to SSMA Female Coaxial Adapter Stainless Steel 40GHZ High Frequency Connector Tester

SKU: EB-DRF-0145-C
Favorites
Key Features
  • 90° angled BNC connector for tight spaces.
  • Compact design saves installation space.
  • Quick connect/disconnect for easy use.
  • Gold-plated PCB mount for reliable performance.
  • OEM quality at a competitive price.
Show More
Attribute
Value
Mounting Type
Cable Type
Shell Finish
Nickel Plated
1st Contact Type
Female Pin
2nd Contact Type
Male Pin
Frequency Max
40 GHz
Shell Material
Stainless steel
Conversion Series
Different Series
Convert From(Adapter 1)
SSMA
1st Connector Fastening Type
Threaded
Convert To(Adapter 2)
2.92mm
2nd Connector Fastening Type
Threaded
Adapter Style
Straight
Description

Electrical:
  • lmpedance: 50Ω
  • Frequency: DC-40GHz
  • VSWR: ≤1.2
  • Dielectric withstanding voltage: 750v(rms)
  • Center contar resistance /2.92mm: ≤3MΩ
  • Outer contart resistance/2.92mm: ≤2MΩ
  • Center contar resistance /SSMA: ≤4MΩ
  • Outer contart resistance/SSMA: ≤2.5MΩ
  • Insulation resistance: ≥1000MΩ

Environmental &Mechanical:
  • Temperture range: -45 ~+165°
  • Rohs Compliant: RoHS
  • Durability: 500cycles

Material and Plating:
  • Inner Contact: beryllium-copper, gold plated
  • Outer Contact: Stainless Steel,Passivated
  • Insulators: PEI

Typical Use Cases Include:
• 5G mmWave Networks and Communications Infrastructure
• High-frequency, small cell-based wireless access points
• MIMO ultra-high-speed outdoor backhaul fixed and moving wireless access points
• Test and measurement instrumentation
• High-speed, Mil-Aero, SATCOM, and instrumentation applications
