| PIN No. | Symbol | Description |
| 1 | GND | Ground |
| 2 | VCC | Power supply for LCD (3.3V) |
| 3 | CLK | This pin is used serial interface clock in 4-wire 8-bit serial data interface. |
| 4 | MOSI | Serial input signal. The data is applied on the rising edge of the SCL signal. |
| 5 | RES | LCM Reset pin Signal is active low. |
| 6 | DC | Data Command Control. This pin is Data Command ccaitrd pin. When the pin is pulled high, the input at D7-D0 is treated as display data. When the pin is pulled low, the input at D7 ~D0 will be transferred to the ccmmand register |
| 7 | BLK | BLK is a backlight control pin, which can be left unconnected by default; BLK should be connected to low level when the backlight is turned off. |
| 8 | MISO | Font output / LCD data output (for reading internal screen data) |
| 9 | CS1 | LCD screen chip selection |
| 10 | CS2 | Font chip chip selection |
